Motorised Acrylic Rolling Shutters
Acrylic Rolling shutters which help in easy visibility widely used in areas where ventilation is required. And we’re structure doesn’t support heavy weight, These shutters allow full ventilation and our display is visible for our window shopper. We use high-quality materials to manufacture these shutters. These shutters are developed and designed in compliance using the high-grade raw material in compliance with international quality standards.
All the shutters offered by us are widely demanded in the market for their integral strength and a high degree of security. Acrylic rolling shutters sourced from the reliable and certified vendors of the market. Our expert quality inspectors check the acrylic rolling shutters on functionality and finishing parameters before dealing with the clients
Our clear shutters allow 90% transparency through the opening, more than any Perspex or acrylic retail roller shutters. This enables you to market your products and messages to potential clients on shop displays and through security screens around the clock, whilst your transparent, high security shop shutters provide 24 hour protection for your business. Clear roller shutters are an excellent solution allowing visibility and security, without compromising on either.
-
Our shutters are manufactured from the best quality metals which ensure long lasting performance
-
The bottom profile of the door is incorporated with additional stiffeners to provide an additional strength
-
Steel, aluminums or stainless steel grill rolling shutters are available in various designs
-
Our shutters are manufactured from the best quality metals which ensure long lasting performance
-
Our drives have weight carrying capacity until 2500Kgs
-
Motorised rolling shutters are self sufficient and can be operated by a single push button
-
Our shutters are in-build with high performance drives and intelligent controls
-
In case of power failure, these doors can be operated manually using a hand crank or chain drive
-
Our Drives are inbuilt with Special Anti Drop device and additional Electromagnetic brake to ensure that the door does not free-fall in any worst conditions
-
Finger-tip control to open and close shutters of any size with the utmost ease from a single push-button switch or a radio remote control transmitter
-
Noiseless operation and Excellent strength
-
Easy installation and Low maintenance
-
Our shutters are manufactured from the best quality metals which ensure long lasting performance
-
Grill rolling shutters are one of the options that you may choose as your shutter curtain among the many types of roller shutters
-
Grill rolling shutters are light but strong and allow air ventilation while ideal for creating a friendly barrier from the outside
PRODUCT |
Motorised Acrylic Rolling Shutter |
||
SHUTTER DIMENSION |
|||
| Width Min./Max. | 1000/3000mm | ||
| Height Min./Max. | 1000/5000mm Max. Area 15.0Sqm Large dimensions on request |
||
| Opening Direction | Vertical | ||
| Mounting Location | Center/Inside | ||
| Opening/Closing Speed | 0.05-0.1mtr /sec | ||
| Mounting Surface | Concrete, Steel | ||
SHUTTER STRUCTURE |
|||
| Slat Material | Acrylic (3 mm thick) | ||
| Slat Profile | Flat profile interlocked by SS linked rods | ||
| Side Guide | Aluminium profile with Rubber inserts on both ends | ||
| Bottom Profile | Aluminium profile with Bottom Rubber sealing | ||
| Roller Shaft | Heavy duty GI Steel strong suspension Tubular shaft without springs | ||
| Side Brackets | M.S plate 3mm to 10mm,as per the opening dimension | ||
| Hood Cover | Galvanized Steel or Stainless Steel sheet | ||
FINISH |
|||
| Surface Finish | Standard Off White Color Special Color on request |
||
DETAILS FOR AUTOMATION SYSTEM |
|||
| Control Type | Casing made of compact impact-resistant material incorporating operating buttons for shutter operation. Specific IP rating provided as per the requirement. Deadman/Pulse Control suggested application wise. |
||
| Drive Type | Imported make Indirect /Direct Connecting Drive selection made depending on the space opening availability, no of operations subjected etc. Drive with integral breaking system with Long life expectancy |
||
| Drive Unit | Electric Motor(Imported Make) Single Phase/Three Phase | ||
| Emergency Operation | Manual operation by Hand chain or hand crank | ||
| Options Available | Perforation In Slat profile Rolling Grill Wicket Door for pedestrian entry Vision windows at human height level |
||
| Accessories(Optional) can be integrated with advanced control |
|
||
-
1
Hospitals
-
2
Pharmaceutical
-
3
Aircraft
-
4
Shipyards
-
5
Food Industries
-
6
Retail & Mall
-
7
Automobiles
-
8
Engineering
-
9
Logistics
-
10
Villa Residency
-
11
Chemical Industries
-
12
Educational Institutions
